Description
The Realtek RTL8188CEBT is a half-size Mini PCI Express combo wireless card built around the RTL8188CE WLAN chipset. It combines 2.4 GHz 802.11b/g/n Wi-Fi with Bluetooth, making it a replacement option for compatible laptops and compact computers.
Technical specifications
- Manufacturer / WLAN chipset: Realtek RTL8188CE / RTL8188CEBT
- Card part number: 6-88-C55SF-5300
- Form factor: Half-size Mini PCI Express (Mini Card), not M.2
- Wi-Fi standards: IEEE 802.11b/g/n
- Wi-Fi band: 2.4 GHz
- Maximum Wi-Fi PHY rate: Up to 150 Mbps
- Bluetooth: Version 2.1 + EDR
- Host interface: PCI Express for WLAN; USB 2.0 for Bluetooth through the Mini Card connector
- Nominal supply: 3.3 V
- Regulatory marking: FCC ID TX2-RTL8188CEBT
- Other label: WLAN MAC address begins 001C7B75E…
- Approximate introduction: 2010
Condition and identification
The card is in clean physical condition, with legible regulatory stickers on both sides and undamaged edge-connector contacts. It is offered as a functional wireless module.
Compatibility: Confirm that your computer has a compatible half-size Mini PCI Express slot. Wi-Fi uses the PCIe interface, while Bluetooth uses the slot’s USB signals, so Bluetooth availability depends on the host’s internal wiring and drivers. Compatible antenna leads and operating-system drivers are also required. This card is not an M.2 module.
Image notice: The current listing image is a photo-pending placeholder, not a photograph of the actual module. Actual item photographs are pending.
